Description
| Technical Specifications | ||
|---|---|---|
| Product | EONLVST | |
| Base Chassis | HCX® Eon Series EON2SE | |
| Case Form Factor | 2U 19″ Rackmount | |
| Operating System | None | |
| Hardware | Motherboard | Supermicro® X13SAE LGA1700 ATX |
| CPU | Intel® Core i9 14900K 6.0GHz (24/32) | |
| RAM | 128GB (4 x 32GB DDR5 4400MT/s unbuffered ECC DIMM) ² | |
| GPU 0 | Nvidia® RTX 4080 16GB GDDR6X ² | |
| GPU 1 | Intel® Arc A770 16GB GDDR6 ² | |
| Storage | Samsung® 990 Pro 2TB PCIe 4.0 NVMe M.2 SSD, upgradeable to 4TB or 8TB (2 x 4TB) ¹ | |
| PSU | AcBel® 2U CRPS 1+1 Redundant 1600W 80+ Platinum ² | |
| Storage Expansion | 4 x 2.5″ HDD/SSD SATA III/SAS hot-swap front drive bays to SATA III 6Gbps (optional SATA III/SAS to SAS 12Gbps ¹) | |
| CPU Cooler | 240W 2U LGA1700 server-grade 2,600-8,000RPM CPU radiator | |
| Cooling | 3 x 80mm hot-swappable 6,500RPM 85.2CFM PWM middle fans | |
| Dust Filtering | No | |
| Front Panel | Power Switch | 1 |
| Reset Switch | 1 | |
| USB 2.0 | 0 | |
| USB 3.0 | 2 | |
| Serial | 0 | |
| Display Output | VGA (to internal 10-pins JVGA header) | |
| Indicators | Power, HDD, LAN1, LAN2, LAN3, Alarm | |
| Color | Black, Silver | |
| Material | SGCC 1.2mm, SGCC 1mm | |
| Dimensions | L650 x W482 x H88 mm | |
| Weight | 30.00 kg | |
| Packaging | ||
| Dimensions | L830 x W555 x H240 mm | |
| Weight | 30.00 kg | |
| What’s Included | ||
|
||
¹ Optional upgrades, additional costs apply. ² Parts brand/OEM may vary based on availability.
