Description
| Technical Specifications | ||
|---|---|---|
| Product | NDBE3600 | |
| Product Revision | rev 1.0 | |
| CPU | Quad-Core Broadcom® BCM6764L 2.0GHz ARMv8 SoC | |
| RAM | 512MB | |
| Flash Memory | 256MB | |
| Wireless Controller(s) | Broadcom® BCM6764L | |
| Wired Controller(s) | Broadcom® BCM53134 | |
| WAN Port(s) | 1 x 2.5Gbps (IEEE 802.3bz) Ethernet | |
| LAN Port(s) | 4 x Gigabit Ethernet | |
| USB Port(s) | 1 x USB 3.1 Gen 1 | |
| Wireless Frequencies |
|
|
| Max. Channel Bandwidth | 160 MHz (EHT160) | |
| Wireless Encryption | WPA3-SAE, WPA2-PSK, WPA-Enterprise | |
| Regional Wireless Channels | EU/UK (ETSI), USA (FCC), Japan, South Korea, China | |
| Antenna Gain |
|
|
| IEEE Compliance |
|
|
| WFA Compliance |
|
|
| Advanced Functionalities |
|
|
| Modulation Schemes |
|
|
| Meshing Technology | WFA EasyMesh® | |
| Power Requirements | 18W (12V/1.5A power supply) | |
| Dimensions | 240 x 170 x 56 mm (without antennas) | |
| Weight | 0.50 kg | |
| Additional Information | ||
| Regulatory Compliance | FCC Part 15 Class B, CE, RoHS | |
| Operating Environment | Temperature: 0 ℃ to 40 ℃ Relative Humidity: 10%-90% (non-condensing) |
|
| Storage Environment | Temperature: -20℃ to 70℃ Relative Humidity: 10%-90% (non-condensing) |
|
| MTBF | >50,000h @ 25°C | |
| Packaging | ||
| Contents |
|
|
| Dimensions | 350 x 350 x 70 mm | |
| Weight | 0.65 kg | |
